Description
connections:
Suction and discharge (for all building materials): 2.0″ Rosca ANSI B16.5 # 150.
Aluminum and Stainless Steel Pumps, they also have: 2.0 Rosca ANSI B16.5 # 150 y Rosca Interior Hembra de 2.0″ NPT.
Air entrance (included Ball valve): 3/4″ Female NPT Thread.
Air vent (Muffler included): 1″Female NPT Thread.
Check valve – Kind, Available:
She was.
Pump Construction – Wet Part, materials available:
Polypropylene (PPG).
Kynar (PVDF).
Aluminum.
Stainless steel (316).
Molten iron.
Diaphragm – materials available:
Neoprene (CR) 82??C (180??F).
Hi (NBR) 82??C (180??F).
Nordel (EPDM) 100??C (212??F).
Hytrel (TPE) 120??C (248??F).
Santropreno (TPO) 100??C (212??F).
Viton (FPM) 120??C (248??F).
Teflon (PTFE) 100??C (212??F).
